Martin D60B20H
Martin D60B20H Double Strand Solid Stock Bore Type B Single Roller Chain Sprocket, 1 in Dia Bore, 5.185 in OD, 60-2 Chain, 20 Teeth, 3/4 in Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand: Martin
- BSC Item#: D60B20H
- MPN: D60B20H
- UPC: 697950018638
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
-
Login to see price
Martin double strand solid construction sprockets have proper spacing between chain rows. The sprockets are manufactured from high carbon steel. Martin does not stack "A" plates on multiples, but instead Martin machines teeth after the chain rows are already in place. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, set screws and hardened teeth are quick alterations that can be made.
Martin Single Roller Chain Sprocket, Double Strand Solid Stock Bore Type B, 1 in Bore Dia, 5.185 in Outside Dia, 60-2 Chain, 20 Teeth, 3/4 in Pitch, 4.794 in, 3-3/4 in Hub Dia, 2-1/8 in Length Through Bore, Steel
| Type | : | Double Strand Solid Stock Bore Type B |
| Bore Diameter | : | 1 in |
| Outside Diameter | : | 5.185 in |
| Chain Size | : | 60-2 |
| Number of Teeth | : | 20 |
| Pitch | : | 3/4 in |
| Pitch Diameter | : | 4.794 in |
| Hub Diameter | : | 3-3/4 in |
| Length Through Bore | : | 2-1/8 in |
| Material | : | Steel |
