Sealmaster®
705029

Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.

Sealmaster® ERX-TREME™ Flange Mount Ball Bearing Unit, Standard-Duty Straight Bore, Series: ERX XLO, 1-1/4 in Bore, 1/16 in Overall Depth, 2.4409 in Overall Height, Set Screw Locking Device, Steel Bearing, Felt Seal, 4381 lb Dynamic/2567 lb Static Load, 2150 rpm Maximum, -20 to 200 deg F, Uncoated

• Wide outer ring
• Lock pin and dimple system
• The felt seal with flinger provides a tight labyrinth seal which retains lubrication and acts as a filter to exclude contamination
• Single setscrew locking is 120 deg spaced, balanced three point contact minimizes inner ring distortion vibration, reduces noise and improves reliability
• Land riding retainer
• Light oil lube grease
• 52100 black oxide coated steel bearing
• Stamped steel rubber mounted flange
• Solid cast iron housing
• ER style cylindrical OD bearing with snap and with black oxided bearing rings_x005f Zone hardened inner ring with 120 deg spacing setscrew lock with diamond faceted setscrews_x005f Extra low drag seal cut down felt labyrinth seal and flinger_x005f Oil lubricated for reduced internal friction_x005f Nylon retainer to reduce overall drag

• Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Sealmaster_ERX18XLO_Specification_Sheet.pdf
• Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Sealmaster_RB10_Manual.pdf
