Thomson® 8106-448-006 8106-448-006 THOM
Send NoImagePrint
  1. pin-int

Thomson®
8106-448-006

Thomson® 8106-448-006 MAR Legacy Type A Non-Preloaded Round Ball Nut, 0.631 in Dia Screw, 0.2 in, 1 Circuits, 1.13 in OD

  • Manufacturer: Thomson Industries
  • Brand: Thomson®
  • BSC Item#: 8106-448-006 THOM
  • MPN: 8106-448-006
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

Thomson® Ball Nut, Type A Non-Preloaded Round, Series: MAR Legacy, 0.631 in Screw Diameter, 1.13 in OD, 1 Circuits, 1.72 in Nut Length, 15/16-16 UN-2A Thread, Right Thread, 0.2 in Thread Lead, 800 lb Dynamic/6150 lb Static Load, For Use With: MAR Legacy Precision Rolled Ball Screw, Steel, Black Oxide

  • 300 deg F operating temperature
  • Nut only, screw sold separately
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Thomson_5703263_Catalog.pdf
Standard/Approvals      :      RoHS Compliant
Application      :      Industrial and Transport Grade Applications
