Gates® Power Transmission SS 1210 .7/8 SS1210-7/8 GATE
Send NoImagePrint
  1. pin-int

Gates® Power Transmission
SS 1210 .7/8

Gates® Power Transmission SS 1210 .7/8 Finished Bore Taper Lock Bushing, 7/8 in Dia Bore, 1-7/8 in Dia Barrel, 1 in OAL, Stainless Steel

  • Manufacturer: Gates Corp
  • Brand: Gates® Power Transmission
  • BSC Item#: SS1210-7/8 GATE
  • MPN: SS 1210 .7/8
  • UPC: 072053814507
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

Gates Taper-Lock® bushings are flangeless for clean, compact application. They are engineered with an 8° taper and a flush-mounted design with no protruding parts providing secure locking and elimination of wobble. The durable stainless steel construction is ideal for food and beverage applications or where non-corrosive sprockets are needed to prevent rust.

Gates® Power Transmission Taper Lock Bushing, Finished Bore, 7/8 in Bore Dia, 1-7/8 in Barrel Dia, 2.88 in Hub Dia, 8 deg Taper, 1-3/4 in Bolt Circle, 2 Bolt Holes, 3/8-16 x 5/8 in Screw, 3600 in-lb, 1 in Overall Length, 3/16 x 3/32 in Keyway, Stainless Steel

  • Size 1210 bushing
  • Bushings are made to precise tolerances
  • Stainless steel bushings are corrosion resistant, preventing rust build up and increasing product life
  • pdf Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Gates_78690001_Manual.pdf
  • pdf Full Engineerin... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Gates_78690101_Full_Engineering_Drawing.pdf
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Gates_92406179_Catalog.pdf
Application      :      For the food and beverage market or where non-corrosive sprockets are needed to prevent rust
