Boston Gear® LSA122Y-R
Boston Gear® LSA122Y-R Spiral Miter Gear With Keyway and Setscrew, 5 Diametral Pitch, Right Hand Tooth Spiral, 20 deg Pressure Angle, 25 Teeth, 5 in Dia Pitch, 1.15 in W Face, 1-3/8 in Dia Bore, Steel
- Manufacturer: Regal Rexnord
- Brand: Boston Gear®
- BSC Item#: LSA122Y-R BGW
- MPN: LSA122Y-R
- UPC: 781711123188
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
-
Login to see price
Boston miter gears are designed for the transmission of motion and power between two intersecting shafts positioned at a right angle. Miter gears are similar to bevel gears except miter gears are used for 1:1 ratios. Straight tooth miter gears are cut with a generated "Coniflex" tooth form providing increased life and quieter operating conditions. Spiral tooth miter gears are better suited for higher speeds and high torque applications.
Boston Gear® Spiral Miter Gear, 1-3/8 in Bore, 5.26 in OD, 1:1 Gear Ratio, 25 Teeth, 5 Diametral Pitch, 5 in Pitch Diameter, 1.15 in Face Width, 3-1/2 in Diameter Hub, 1-3/4 in Hub Projection, 3.005 in Overall Length, 20 deg Pressure Angle, Right Hand Tooth Spiral, 35 deg Spiral Angle, Steel
- 90 deg intersecting shaft applications provide highly efficient operation
- Unhardened teeth offer versatility
Catalog
| Standard/Approvals | : | PROP65: This product contains lead, known to the State of California to cause cancer and birth defects or other reproductive harm. |
| Application | : | For use with 90 deg intersecting shaft |
