McGill®
4261100000

McGill® Heavy Duty CAMROL® bearings are full complement cylindrical roller bearings, featuring black oxide treated bearing steel. They are available in two basic mounting styles for use in mechanical automation or linear motion applications. The available styles are stud or yoke. Our standard integral flange construction of stud version bearings helps maintain bearing integrity throughout the life. The inch series utilizes a rubber lip seal to provide a barrier for contamination and lubricant retention. The metric series can utilize a metallic shield to provide a barrier for contamination. Within the following section you can learn more about how these and other features can be applied to your application.

McGill® CAMROL® Unmounted Cam Yoke Roller Bearing, Cylindrical OD Heavy Duty, Series: CYRD, 3/4 in Bore Dia, 2-3/4 in Roller Dia, 1-1/2 in Roller Width, 1-9/16 in Overall Width, 15000 lb Dynamic/9790 lb Static, Sealed Closure, 1050 rpm Maximum, -20 to 250 deg F, Chrome Steel Roller, Black Oxide

• Custom design and lubricant
• Double rows of cylindrical rollers for higher, radial load rating and incidental thrust capacity
• A heavy sectioned outer race design to help withstand shock loading of cam follower operation
• Inner studs are heat treated in the roller path and flange surfaces
• Black oxide finish on all external surfaces helps inhibit corrosion
• Inch series Heavy Duty CAMROL® bearings have a large lubricant reservoir design and inward pointed rubber lips
• Standard providing reduced maintenance operation
• Cylindrical roller bearing element

• Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/McGill_4141200000_Specification_Sheet.pdf
• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/McGill_4145510000_Catalog.pdf
• Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/McGill_4145510000_Manual.pdf
