  1. pin-int

Browning®
1069202

Browning® 1069202 Type G Split-Taper Bushing, 12 mm Dia Bore, 1.133 in Dia Small End/1.172 in Dia Large End Dia Barrel, 2 in Dia Flange, 1 in OAL, Sintered Steel

  • Manufacturer: Regal Rexnord
  • Brand: Browning®
  • BSC Item#: G12MM BRWN
  • MPN: 1069202
  • UPC: 662289351473
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: Call for Availability

External key provides positive drive with no torque on the cap screws. We offer high torque carrying capacity. Double split barrel improves true concentricity. The shaft is gripped with positive clamp fit.

Browning® Split-Taper Bushing, Type G, 12 mm Bore, 1.133 in Dia Small End/1.172 in Dia Large End Barrel Diameter, 1.563 in Diameter Bolt Circle, 2 in Diameter Flange, 1/4 in Flange Thickness, 2 Bolt Holes, 1/4 x 5/8 in Screw, For Use With: Gearbelt® Multiple Groove Sheaves, 1 in Overall Length, Sintered Steel

  • Keyed to both shaft and hub, external key provides positive drive with no torque on the cap screws
  • Highest torque carrying capacity
  • Double split barrel assures true concentricity grips the shaft with positive clamp fit
  • Without keyway
  • 3/4 in per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product
  • pdf Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_1071505_Installation_Manual.pdf
  • pdf Warranty Inform... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_A175382_Warranty.pdf
  • pdf Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_G10MM_Specification_Sheet.pdf
Standard/Approvals      :      ABMA/AGMA/AIST/AWEA/CEMA/GEAPS/MPTA/NSSGA/PTDA Standards
Application      :      Aggregate, Cement, Agriculture, HVAC, Minerals, Mining, Packaging Machinery and Unit Handling Industries
