Martin D06B12
Martin D06B12 Double Strand Metric Solid Stock Bore Type B Single Roller Chain Sprocket, 10 mm Dia Bore, 42.358 mm OD, 06B-2 Chain, 12 Teeth, 9.525 mm Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand: Martin
- BSC Item#: D06B12
- MPN: D06B12
- UPC: 697950396118
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
-
Login to see price
Martin metric double strand solid construction sprockets have proper spacing between chain rows. The sprockets are manufactured from high carbon steel. Martin does not stack "A" plates on multiples, but instead Martin machines teeth after the chain rows are already in place. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, set screws and hardened teeth are quick alterations that can be made.
Martin Single Roller Chain Sprocket, Double Strand Metric Solid Stock Bore Type B, 10 mm Bore Dia, 42.358 mm Outside Dia, 06B-2 Chain, 12 Teeth, 9.525 mm Pitch, 36.802 mm, 24.994 mm Hub Dia, 24.994 mm Length Through Bore, Steel
| Type | : | Double Strand Metric Solid Stock Bore Type B |
| Bore Diameter | : | 10 mm |
| Outside Diameter | : | 42.358 mm |
| Chain Size | : | 06B-2 |
| Number of Teeth | : | 12 |
| Pitch | : | 9.525 mm |
| Pitch Diameter | : | 36.802 mm |
| Hub Diameter | : | 24.994 mm |
| Length Through Bore | : | 24.994 mm |
| Material | : | Steel |
