Martin 40BTB19 40BTL19
Send NoImagePrint
  1. pin-int

Martin
40BTB19

Martin 40BTB19 Taper Bushed Type B Single Pitch Roller Chain Sprocket, 3.296 in OD, #40 Chain, 19 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand: Martin
  • BSC Item#: 40BTL19
  • MPN: 40BTB19
  • UPC: 697950030647
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

A taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head set screws instead of bolts.

Martin Single Pitch Roller Chain Sprocket, Taper Bushed Type B, 3.296 in Outside Dia, #40 Chain, 19 Teeth, 1/2 in Pitch, 3.038 in, 2.469 in Hub Dia, 1 in Length Through Bore, 1210 Taper Lock Bushing, Steel

Type      :      Taper Bushed Type B
Outside Diameter      :      3.296 in
Chain Size      :      #40
Number of Teeth      :      19
Pitch      :      1/2 in
Pitch Diameter      :      3.038 in
Hub Diameter      :      2.469 in
Length Through Bore      :      1 in
Bushing Type      :      1210 Taper Lock
Material      :      Steel
  • pdf Catalog https://www.bsc-ind.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_41SH32_Catalog.pdf
Standard/Approvals      :      PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov
