Timken®
RCJT1 1/2 PT

Timken® ball bearing housed units feature a wide-inner-ring ball bearing for additional shaft support. Designed for mounting on straight shafts with a slip fit, these housed units are available in an extensive array of types and sizes to accommodate many industrial applications.

Timken®, RCJT1 1/2 PT, Flange Mount Ball Bearing Unit, Normal Duty PT, Series: RCJT, 1-1/2 in Bore, 5-21/32 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 6-3/4 in Overall Length/Diameter, 2-5/16 in Overall Depth, 4-1/8 in Overall Height, Eccentric Locking Device, Steel Bearing, 7330 lb Dynamic/4460 lb Static Load, 4600 rpm Maximum, -30 to 275 deg F, Uncoated

• This unit is used for the main portion of the process where loads are lighter and corrosion protection is important
• Durable corrosion-proof polymer housing with stainless steel crush bushings in mounting holes and a stainless steel grease fitting with a nylon cap
• The polymer strength exceeds static capacity of bearing housing retains proper bearing fit and resists shock loads
• Corrosion-resistant insert bearing with stainless steel balls and a nylon retainer, the PT series also features industrial duty contact seals with stainless steel shroud-caps
• The flush base contains no voids where bacteria can collect
• This unit has a stainless steel lock collar

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Fafnir_GVFD1_1_2_Catalog.pdf
