Sealmaster®
727687

Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.

Sealmaster® Flange Mount Ball Bearing Unit, Non-Expansion Round Straight Standard-Duty, Series: FB Series, 15/16 in Bore, 2-1/2 in Bolt Center-to-Center Length, 3-Bolt Flange Mounting, 1-13/16 in Overall Length/Diameter, 3/8 in Overall Depth, 3-3/8 in Overall Height, Skwezloc® Locking Locking Device, Steel Bearing, Nitrile Rubber Seal, 2801 lb Dynamic/1651 lb Static Load, 6350 rpm Maximum, -20 to 220 deg F, Uncoated

• Wide outer ring
• Lock pin and dimple system
• Single lip contact seal consists of a nitrile rubber washer in metal shroud to shield the lip from large contaminants
• Zone hardened inner race
• Land riding retainer
• GoldPlex-HP grease
• 52100 black oxide coated steel bearing
• Solid cast iron housing
