Thomson® PPA24-58B65-36NPOX
Thomson® Electrak® PPA-DC PPA24-58B65-36NPOX Heavy Duty Linear Actuator With DC Motor, 1500 lb Dynamic/3000 lb Static Load, 36 in Max Stroke, 0.37 in/s Full Load/0.49 in/s No Load Max, 30 % Duty Cycle, 24 VDC
- Manufacturer: Thomson Industries
- Brand: Thomson®
- BSC Item#: PPA24-58B65-36NPOX THOM
- MPN: PPA24-58B65-36NPOX
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
- Sold As: 1/PK
-
Login to see price
Electrak® PPA-DC performance Pak actuators are strong, heavy duty units able to run at higher duty cycles. Incorporating a highly efficient ball screw drive system, these actuators are designed for mobile applications with a wide selection of options and standard trunnion mounting.
Thomson® Electrak® PPA-DC Linear Actuator, Heavy Duty, 1500 lb Dynamic/3000 lb Static Load, 36 in Maximum Stroke, 0.37 in/s Full Load/0.49 in/s No Load Maximum, 30 % Duty Cycle, 24 VDC, 0 to 24 A, 42.8 in Retracted Length, 49.7 in L x 3.125 in W Dimensions
- Overload clutch for mid and end of stroke protection
- Versatile actuator with high duty cycle
- Auto reset thermal switch motor protection
- Without brake
- No bellows
- -15 to 150 deg F operating temperature
- 16-1/2 in L cable with flying leads
Catalog
| Standard/Approvals | : | CE Certified |
| Application | : | Mobile-off-Highway, Turf and Garden, Energy Alternatives, Industrial, Ventilation, Process Control Equipment, Health, Fitness, Office, Domestic and Entertainment Equipments |
