Browning® 3195591 BK72-1-3/8
Send NoImagePrint
  1. pin-int

Browning®
3195591

Browning® Classical Gripbelt® 3195591 BK Series Type 3 Single Groove Sheave, Finished Bore, 1-3/8 in Dia Bore, 6.95 in OD, 6.4 in (A)/6.9 in (B) Dia Pitch, 7/8 in W Face

  • Manufacturer: Regal Rexnord
  • Brand: Browning®
  • BSC Item#: BK72-1-3/8
  • MPN: 3195591
  • UPC: 662289591442
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

Browning® Classical Gripbelt® Single Groove Sheave, Type 3, Series: BK Series, Finished Bore, 1-3/8 in Bore Dia, 6.95 in Outside Dia, 6.4 in (A)/6.9 in (B), 7/8 in Face Width, 21/32 in Hub Projection, 1-17/32 in Overall Length, For Use With: 4L/A and 5L/B Cross Section Belt, Cast Iron

  • External rib design provides cooling for longer belt life
  • Increases wall thickness by 30%
  • Increased hub diameter by 20%
  • Tighter tolerances by 25%
  • Twice balanced after assembly
  • Tightened micro-finish on groove walls for increased belt life
  • Precision balanced to provide smooth, vibration free performance
  • Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration
  • 1 and 2 Grooves are available to meet any fractional horsepower requirement
  • Combination Groove - All Browning BK Sheaves permit the running of A, 4L, B and 5L Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_AK46HCLEARPK_Catalog.pdf
Application      :      Agitators, Blowers and Exhausters, Belt Conveyors, Generators, Laundry Machinery, Machine Tools, Printing Machinery, Brick Machinery, Bucket Elevators, Exciters, Piston Compressors, Hammer Mils, Paper Mill Beaters, Piston Pumps, Positive Displacement Blowers and Rotary Pumps and Pulverizer Industries
