NTN 5206NR
NTN 5206NR 52 Series Round Bore Angular Contact Ball Bearing, 30 mm Dia Bore, 62 mm OD, 2 Rows, 23.8 mm W, 25 deg, 29600 N Load
- Manufacturer: NTN
- Brand: NTN
- BSC Item#: 5206NR NTN
- MPN: 5206NR
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
- Sold As: 60/PK
-
Login to see price
Double Row Angular Contact Ball Bearings have an inner and outer ring with a double raceway. The two rows are so related that the contact angle is similar to a pair of back-to-back single row bearings. The 5200 and 5300 series offer continuous races and can carry thrust loads in either direction. Since the 3200 and 3300 series have filling slots, it is necessary to mount them with the thrust load acting against the unnotched face of the rings.
NTN Angular Contact Ball Bearing, Round Bore, Series: 52 Series, 30 mm Bore Dia, 62 mm Outside Dia, 2 Rows, 23.8 mm W, 25 deg Contact, Open Closure, 29600 N, High Carbon Chrome Steel Bearing, Pressed Steel Cage, 7100 rpm Grease/9500 rpm Oil Maximum, -40 to 120 deg C
| Bore Diameter | : | 30 mm |
- Without filling slot
- Normal clearance
- ISO class 0 precision rating
- Snap ring groove on outer ring, snap ring included
- 29600 N dynamic/21100 N static
Catalog
| Standard/Approvals | : | AAIA|ABMA|ABEC 1|AEM|BSA|JIS B 1514|PTDA |
| Application | : | Construction, Wind Energy, Metals Manufacturing, Mining, Food and Beverage, Precision and Machine Tools, Paper and Forestry, Oil and Gas, Agriculture and Electric Motors |
