Martin 2062A20 Conveyor Solid Stock Bore Type A Double Pitch Roller Chain Sprocket, 0.938 in Dia Bore, 10.37 in OD, 2062 Chain, 20 Teeth, 1-1/2 in Pitch, Steel
Double pitch sprockets have rollers of the same diameters and widths as American Standard roller chains of one half the conveyor chain pitch. Engaged by every other tooth, double duty sprockets have two teeth per chain pitch. During each revolution only half the teeth function effectively. Sprockets with odd numbers of teeth will allow any given tooth to engage only on every other revolution, automatically increasing sprocket life. Double duty sprockets with even number of teeth may be manually advanced one tooth periodically to increase sprocket life.
Martin Double Pitch Roller Chain Sprocket, Solid Stock Bore Type A, Series: Conveyor, 0.938 in Bore Dia, 10.37 in Outside Dia, 2062 Chain, 20 Teeth, 1-1/2 in Pitch, 9.589 in, 4-1/4 in Hub Dia, 0.459 in Length Through Bore, Steel
Type | : | Solid Stock Bore Type A |
Series | : | Conveyor |
Bore Diameter | : | 0.938 in |
Outside Diameter | : | 10.37 in |
Chain Size | : | 2062 |
Number of Teeth | : | 20 |
Pitch | : | 1-1/2 in |
Pitch Diameter | : | 9.589 in |
Hub Diameter | : | 4-1/4 in |
Length Through Bore | : | 0.459 in |
Material | : | Steel |
