Martin 2 3V 315 TB
Martin Hi-Cap® 2 3V 315 TB Solid Type A-1 Wedge Stock Sheave, 0.5 to 1.26 in TB Bushed Bore, 3.15 in OD, 2 Grooves, 3.1 in Dia Pitch, 1.94 in W Face
- Manufacturer: Martin Sprocket & Gear
- Brand: Martin
- BSC Item#: 2/3V3.15TL MART
- MPN: 2 3V 315 TB
- UPC: 697950154145
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
-
Login to see price
Hi-Cap® sheaves (narrow V-belts) are manufactured from class 30 gray iron (30,000 tensile strength) and can have a maximum speed of 65 fpm. All Martin sheaves are statically balanced. Dynamic balancing should be considered for any sheaves exceeding 5 fpm, or if they will be used on equipment where vibration is a problem. Martin has extensive inventories of both QD and TB style V-belt sheaves to run with 3V, 5V, and 8V belts.
Martin Hi-Cap® Wedge Stock Sheave, Solid Type A-1, TB Bushed Bore, 0.5 to 1.26 in Bore, 3.15 in OD, 3.1 in Pitch Diameter, 2 Grooves, 1.94 in Face Width, 121 Bushing, 1.09 in Overall Length, For Use With: 3V-Cross Section V-Belts, Cast Iron
- Class 30 Gray Iron
- Tolerances adhere to industry guidelines
- Precise machining and processes ensure consistent finish and high quality
- Statically balanced with maximum rim speed marked on print
