Baldor-Reliance L1408TM
Baldor-Reliance L1408TM Type 3634LC Continuous Duty Definite Purpose AC Motor, Open Enclosure, 3 hp, 115/230 VAC, 60 Hz, 1 Phase, 184T Frame, 1725 rpm Speed, Foot Rigid Mounting
- Manufacturer: ABB Baldor-Reliance
- Brand: Baldor-Reliance
- BSC Item#: L1408TM BLDR
- MPN: L1408TM
- UPC: 781568101612
- Min. Order Qty: 1
- Qty. Interval: 1 Availability: Call for Availability
- Sold As: EACH
-
Login to see price
Single phase and three phase general purpose motors are designed to meet or exceed the energy efficiency requirements of the United States, Canada and Mexico for general purpose industrial motors, while delivering high starting torque, overload capability and superior reliability. The extensive line of general purpose motors are available in ok wide variety of enclosure construction from industrial steel band open designs where water and dust exposure is moderate, to totally enclosed cast iron designs where exposure to water, dust and corrosives exists. The Super-E® motors provide NEMA premium efficiency and are inverter ready with wide variable torque speed ranges as standard. For motors with features outside the capabilities below, please contact your Baldor-Reliance sales representative.
Baldor-Reliance, L1408TM, Definite Purpose AC Motor, Type 3634LC Continuous Duty, General Purpose AC Motors Application, 3 hp, 115/230 VAC, 32/16 A, 60 Hz Frequency, 1 ph, 1725 rpm Speed, 1 Speed, Open Enclosure, 184T Frame, 1-1/8 in Shaft, Reversible Rotation, 1.15 Service Factor, Ball Bearing, 21 ft-lb Torque, Foot Rigid Mounting, 40 to 76 deg C, Steel, 15 in L x 11.47 in W x 10.68 in H Dimensions
| Type | : | Type 3634LC Continuous Duty |
| Application Type | : | General Purpose AC Motors |
| Horsepower | : | 3 hp |
| Voltage Rating | : | 115/230 VAC |
| Amperage Rating | : | 32/16 A |
| Frequency Rating | : | 60 Hz |
| Phase | : | 1 |
| Speed | : | 1725 rpm |
| Number of Speeds | : | 1 |
| Enclosure Type | : | Open |
| Frame | : | 184T |
| Shaft Size | : | 1-1/8 in |
| Rotation | : | Reversible |
| Service Factor | : | 1.15 |
| Bearing Type | : | Ball |
| Torque Rating | : | 21 ft-lb |
| Mounting Type | : | Foot Rigid |
| Temperature Rating | : | 40 to 76 deg C |
| Insulation Class | : | Class F |
| Material | : | Steel |
| Dimensions | : | 15 in L x 11.47 in W x 10.68 in H |
- Low noise vibration dampening base
- Dynamically balanced rotor to increase bearing life
- Optimized airflow design providing higher horse power in ok smaller package
- Low noise design
- Superior switch design provides optimized torque profiles
- Robust heavy gauge steel design
Catalog
| Standard/Approvals | : | ARRA Compliant|Buy American Act Compliant|UR Listed|CSA EEV Certified |
| Application | : | Air Handling, Material Handling, Machine Tools, Conveyors, Pumps and Fans Applications |
