Lovejoy®
68514410215

Lovejoy® 68514410215 Type L Style 1 Jaw Coupling Hub With Setscrew, L050 Coupling, 7 mm Dia Bore, 15.75 mm L Through Bore, 27.43 mm Dia Hub, Sintered Iron

Manufacturer: Lovejoy
Brand: Lovejoy®
BSC Item#: 0685144102157 LOVJ
MPN: 68514410215
UPC: 685144102157
CPN:
Min. Order Qty: 1
Qty. Interval: 1

Availability:

Call for Availability

Login to see price
Add To Cart
My List
Add / Remove CPN

DESCRIPTION
FEATURES
Documents
ADDITIONAL INFO

Lovejoy® Jaw Coupling Hub, Type L Style 1, L050 Coupling, 7 mm Bore, 27.43 mm Diameter Hub, 27.94 mm Hub Length, 18000 rpm Maximum, 15.75 mm Length Through Bore, 1/4-20 Screw, Sintered Iron, Metallic

Fail safe - will still perform if elastomer fails
No metal to metal contact
Resistant to oil, dirt, sand, moisture and grease
More than 850000 combinations of bore sizes
Without keyway

Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514410124_Catalog.pdf
Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514410124_Manual.pdf
Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514410215_Specification_Sheet.pdf
