Lovejoy®
69790400001

Lovejoy®/Sier-Bath® Nylon couplings are compact and require no lubrication. They operate over a wide temperature range at speeds up to 5000 rpm and are effectively used in applications such as Motor/Generator sets, pump sets and many light to medium duty industrial coupling applications. No lubricants are ever required, eliminating the need for seals. The resilient nature of the nylon material makes the contact of the hubs and sleeves almost frictionless. Since no lubrication is used, the coupling can readily be adapted to many applications including vertical and blind installations where the slip-together components offer easy inspection and adjustment. Operationally, the coupling offers a minimum backlash solution that will operate in ambient temperature environments from -40 to 150 deg F. Nylon Sleeve couplings have precision molded sleeves and hubs with no bolts, pins, flanges or protrusions to affect balance or safety. The nylon sleeve permits misalignment up to 5 deg for Dentex® and Nyflex® couplings and 3 deg for the Mite®. When completely assembled, the Mite® coupling weighs less than 1 lb and the Nyflex® only 3.5 lb. The Nyflex® and Mite® coupling consists of two sintered iron flex hubs, one Nylon sleeve and two Spiirolox rings.

Lovejoy® Mite® Gear Coupling Hub, Finished Bore, 1/2 in Bore, 1-3/4 in Diameter Hub, 1/8 in W x 1/16 in D Keyway, 5000 rpm Maximum, 1.13 in Length Through Bore, 1/4-20 Screw, Sintered Iron, Metallic

• No lubrication required eliminating the need for seals
• Sintered Iron hubs with crowned teeth to provider greater misalignment and gouging of nylon sleeve
• Resilient, lightweight, abrasion and corrosion-resistant nylon sleeve accurately molded to mesh with hubs eliminating friction and need of lubrication
• Center groove in sleeves readily permits their use in vertical applications and for blind assembly
• Securely held hubs and sleeves by spring-steel retaining rings yet capable of easy removal and still withstand a 5000 lb end thrust
• Minimum backlash operating in an ambient temperature environment of -40 to 150 deg F
