Lovejoy®
69790498406

Lovejoy® Internal Shaft Locking Device, Self-Centering, Series: SLD 1450 Series, 2 in Bore, 3.15 in OD, 2 in Diameter Hub, 1489 ft-lb Transmissible Torque, 19059 psi Shaft Contact Pressure, 18153 psi Hub Contact, M8 Screw, 0.787 in Overall Length, Metallic Collar/Steel Screw, Silver

• Versus traditional keyed connection
• No Backlash due to fit tolerances
• No impact effect from reversing loads
• Ability to adjust axial position and angular timing
• No fretting corrosion due to movement at the fit interface
• Versus traditional interference fits
• Easier and quicker to install
• Higher contact pressures can transmit greater torques
• Easy and quick to remove without damaging the shaft or hub even after years of service
• Eliminate cost of machining keyways or splines
• Reduce the shaft stress by removing keyways or splines
• Eliminating keyways often allows the use of a smaller diameter shaft
• Can place anywhere on shaft and allows for easy angular timing
• Easy removal without damaging the shaft or hub means easier maintenance for your customer
