Deltran
SB-70B24-E24S

Spring-set electromagnetic power-off brakes provide a safe, efficient means of stopping and/or holding a load in the absence of power. While the field (electromagnet) assembly is fixed and prevented from rotating, the rotor assembly is secured to the shaft. In the absence of power, the fixed and rotating components are engaged, thus stopping and/or holding the load. When the coil is energized, rotating components are disengaged, thus allowing the shaft to freely rotate.

Deltran Power-Off Servo Brake, Series: SB Supernuts®, 1-1/2 in Bore, 7-1/4 in OD, 2.77 in Overall Length, 1200 in-lb Static Torque, 24 VDC, 53 W Power, 5000 rpm Maximum, Burnished Steel

• Uni-directional control
• Compact design
• Non-asbestos friction material
• Factory set air gaps no need to adjust
• Interchangeability with many existing brake designs
• Long-life brake lining non-asbestos
• Low inertia rotating components, allowing higher acceleration rates
• UL class H insulation system, epoxy sealed for efficient operation in extreme environments
• Spline drive construction withstands high impact stresses imparted by servo systems
• High temperature, insulated lead wires
• Through holes for internal or external reversible mounting flexibility
• Static or dynamic engagement
• Simple installation
• Economical cost
• Energy efficient
• Short hub
• Holding type motion power-off servo brake
• Size 7.25 frame

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Deltron_24500101_Catalog.pdf
