Martin 200B10 200B10 MART
Send NoImagePrint
  1. pin-int

Martin
200B10

Martin 200B10 Type B Single Strand Solid Reboreable Roller Chain Sprocket, 1-1/2 to 3-3/4 in Dia Bore, 9.194 in OD, #200 Chain, 10 Teeth, 2-1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand: Martin
  • BSC Item#: 200B10 MART
  • MPN: 200B10
  • UPC: 697950028163
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

B Style sprockets are flat sprockets with a hub extension on one side. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, setscrews and harden teeth are quick alterations that can be made.

Martin Roller Chain Sprocket, Type B Single Strand Solid Reboreable, 1-1/2 to 3-3/4 in Bore, 9.194 in OD, #200 Chain, 10 Teeth, 2-1/2 in Pitch, 8.0902 in Pitch Diameter, 5-1/2 in Diameter Hub, 3 in Length Through Bore, Steel

  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • Bores are concentric to pitch line, minimizing run out
  • pdf Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf
Standard/Approvals      :      ANSI Specified|B29.1 - 1975
