Martin
D60CTB68

A taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head setscrews instead of bolts.

Martin Roller Chain Sprocket, Type C Double Strand Solid Bushed, 1/2 to 2-1/2 in Bore, 16.672 in OD, #60 Chain, 68 Teeth, 3/4 in Pitch, 16.240 in Pitch Diameter, 4-1/2 in Diameter Hub, 1-3/4 in Length Through Bore, TB 2517 Bushing, Steel

• Interchangeable with other manufacturer's taper bushings
• Precise machining and processes ensure consistent finish and high quality
• Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
• Bores are concentric to pitch line, minimizing run out

• Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf
