Browning® 3357498 41B24-1
Send NoImagePrint
  1. pin-int

Browning®
3357498

Browning® 3357498 Single Strand Finished Bore Type 1 Roller Chain Sprocket With Keyway, 1 in Dia Bore, 4.098 in OD, #41 Chain, 24 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Regal Rexnord
  • Brand: Browning®
  • BSC Item#: 41B24-1
  • MPN: 3357498
  • UPC: 662289169788
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

Browning® finished bore sprockets are offered in single strands. Offerings include 35 to 100 pitch range. Finished bore sprockets are available from 3/8 to 2-7/16 in. Hardened teeth are available up to 30 teeth.

Browning® Roller Chain Sprocket, Single Strand Finished Bore Type 1, 1 in Bore Dia, 4.098 in Outside Dia, #41 Chain, 24 Teeth, 1/2 in Pitch, 3.831 in, 3.266 in Hub Dia, 1/4 x 1/8 in Keyway, 1 in Length Through Bore, Steel

  • Furnished with standard keyway on centerline of tooth and hollow head setscrew over keyway
  • In-stock hardened sprockets are warranted to last at least twice as long as the standard (unhardened) mild steel sprockets they replace
  • For use with 1/2 in pitch ANSI chain
  • pdf Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_35JA20_Manual.pdf
  • pdf Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_H40SH20_Specification_Sheet.pdf
Standard/Approvals      :      ANSI Specified
Application      :      Aggregate, Cement, Agriculture, Forestry, Minerals, Mining, Pulp and Paper Industries
