Browning® 3746260 35BTL32
Send NoImagePrint
  1. pin-int

Browning®
3746260

Browning® 3746260 Single Strand Roller Chain Sprocket With Hardened Teeth, 1/2 in Dia Bore, 4.032 in OD, #35 Chain, 32 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Regal Rexnord
  • Brand: Browning®
  • BSC Item#: 35BTL32
  • MPN: 3746260
  • UPC: 662289605972
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.

Browning® Roller Chain Sprocket, Single Strand, 1/2 in Bore Dia, 4.032 in Outside Dia, #35 Chain, 32 Teeth, 3/8 in Pitch, 3.826 in, 3-1/4 in Hub Dia, 1 in Length Through Bore, Type 1 Taper Bore Bushing, Steel

  • This product has the Browning® exclusive twice the life guarantee
  • Compact design
  • Hardened teeth at no extra cost, drives sizes up to 30 teeth on 40 through 160 chain
  • 1-11/16 in/ft taper
  • Setscrew or cap screw acts as external key
  • Flush fit, less space on shaft
  • No protruding flange
  • For use with 3/8 in pitch ANSI chain
  • pdf Instruction/Ins... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_35JA20_Manual.pdf
  • pdf Specification S... https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_35TB18_Specification_Sheet.pdf
Standard/Approvals      :      ANSI Specified
Application      :      Aggregate, Cement, Agriculture, Forestry, Minerals, Mining, Pulp and Paper Industries
