Martin 40BTB23 40BTL23 MART
Send NoImagePrint
  1. pin-int

Martin
40BTB23

Martin 40BTB23 Taper Bushed Type B Single Pitch Roller Chain Sprocket, 3.938 in OD, #40 Chain, 23 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand: Martin
  • BSC Item#: 40BTL23 MART
  • MPN: 40BTB23
  • UPC: 697950030685
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

A taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head set screws instead of bolts.

Martin Single Pitch Roller Chain Sprocket, Taper Bushed Type B, 3.938 in Outside Dia, #40 Chain, 23 Teeth, 1/2 in Pitch, 3.672 in, 3.098 in Hub Dia, 1 in Length Through Bore, 1610 Taper Lock Bushing, Steel

  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_41SH32_Catalog.pdf
Standard/Approvals      :      PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov
