Martin 35BS17 1/2 35B17-1/2 MART
Send NoImagePrint
  1. pin-int

Martin
35BS17 1/2

Martin 35BS17 1/2 Bored-to-Size Type BS Single Pitch Roller Chain Sprocket, 1/2 in Dia Bore, 2.231 in OD, #35 Chain, 17 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand: Martin
  • BSC Item#: 35B17-1/2 MART
  • MPN: 35BS17 1/2
  • UPC: 697950001258
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Availability: Call for Availability

These finished bore sprockets are shaft ready and come complete with keyways and setscrews. The keyways are on center line of the tooth. Bored to size sprockets with 1/2 in bores and smaller are stocked with (2) setscrews only.

Martin Single Pitch Roller Chain Sprocket, Bored-to-Size Type BS, 1/2 in Bore Dia, 2.231 in Outside Dia, #35 Chain, 17 Teeth, 3/8 in Pitch, 2.041 in, 1.594 in Hub Dia, 1/4-20 x 1/4 in Screw, 1/8 x 1/16 in Keyway, 3/4 in Length Through Bore, Steel

  • Stock finished bores
  • Non-hardened teeth
  • Precise machining and processes ensure consistent finish and high quality
  • Bores are concentric to pitch line, minimizing run out
  • 2 set screws keyed on centerline of tooth
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_41SH32_Catalog.pdf
