SMC®
KQ2H07-M5A

SMC® KQ2H07-M5A KQ2 Inch Size with Gasket One-Touch Fittings, 1/4 in x M5 x 0.8 Nominal, Push-In End Style, Brass

  • Manufacturer: SMC Corporation of America
  • Brand: SMC®
  • BSC Item#: KQ2H07M5A SMC
  • MPN: KQ2H07-M5A
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: Call for Availability

SMC®, KQ2H07-M5A, One-Touch Fittings, Inch Size with Gasket, Series: KQ2, Fitting/Connector: Connector, 1/4 in x M5 x 0.8 Nominal, Push-In End Style, 11 mm Hex, 18.4 mm Length, -100 kPa to 1 MPa Pressure, -5 to 60 deg C Air, 0 to 40 deg C Water Operating, Brass, White/Light Gray

  • Operating pressure range from 100kPa to 1MPa
  • Release collar allows easy removal of tubing without causing damage to the tube
  • This product is not intended for use in potable water systems
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/SMC_KQ2T11_35AS_Catalog.pdf
Standard/Approvals      :      RoHS Compliant
Application      :      For use in potable water systems
